| Pixel | P2.5 | P2.604 | P2.976 | P3.91 | P4.81 | P5.2 | P6.25 |
|---|---|---|---|---|---|---|---|
| Module Composition | |||||||
| Pixel composition | SMD LED 1R,1G,1B | SMD LED 1R,1G,1B | SMD LED 1R,1G,1B | SMD LED 1R,1G,1B | SMD LED 1R,1G,1B | SMD LED 1R,1G,1B | SMD LED 1R,1G,1B |
| Pixel pitch(W*H)mm | 2.5*2.5 | 2.604*2.604 | 2.976*2.976 | 3.91*3.91 | 4.81*4.81 | 5.2*5.2 | 6.25*6.25 |
| Module resolution(W*H) | 100*100 | 96*96 | 84*84 | 64*84 | 52*52 | 48*48 | 40*40 |
| Module size(W*H*D)mm | 250*250*18 | 250*250*18 | 250*250*18 | 250*250*18 | 250*250*18 | 250*250*18 | 250*250*18 |
| Module weight(KG) | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
| Panel Unit Composition | |||||||
| Contains modules qty(W*H) | 2*2 / 2*4 | 2*2 / 2*4 | 2*2 / 2*4 | 2*2 / 2*4 | 2*2 / 2*4 | 2*2 / 2*4 | 2*2 / 2*4 |
| Panel resolution(W*H) | 200*200 / 200*400 | 192*192 / 192*384 | 168*168 / 168*336 | 128*128 / 128*256 | 104*104 / 104*208 | 96*96 / 96*192 | 80*80 / 80*160 |
| Panel size(W*H*D)mm | 500*500*78 / 500*1000*78 | 500*500*78 / 500*1000*78 | 500*500*78 / 500*1000*78 | 500*500*78 / 500*1000*78 | 500*500*78 / 500*1000*78 | 500*500*78 / 500*1000*78 | 500*500*78 / 500*1000*78 |
| Resolution(dots/m²) | 160000 | 147456 | 112896 | 65536 | 43264 | 36864 | 25600 |
| Protection level | Indoor (front IP54, back IP43) | Indoor (front IP54, back IP43) | Indoor (front IP54, back IP43) | Indoor (front IP54, back IP43) | Indoor (front IP54, back IP43) | Indoor (front IP54, back IP43) | Indoor (front IP54, back IP43) |
| Panel flatness(mm) | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 |
| Brightness(nits) | Indoor ≥1300 | Indoor ≥1300 | Indoor ≥1300 | Indoor ≥1300 | Indoor ≥1300 | Indoor ≥1300 | Indoor ≥1300 |
| Color temperature(K) | 6000—9300 adjustable | 6000—9300 adjustable | 6000—9300 adjustable | 6000—9300 adjustable | 6000—9300 adjustable | 6000—9300 adjustable | 6000—9300 adjustable |
| View angle(°) | >120 | >120 | >120 | >120 | >120 | >120 | >120 |
| Electrical Parameters | |||||||
| Power consumption | DC6~7 | DC6~7 | DC6~7 | DC6~7 | DC6~7 | DC6~7 | DC6~7 |
| Peak/Average Power (W/m²) | 800 / 300 | 800 / 300 | 800 / 300 | 800 / 300 | 800 / 300 | 800 / 300 | 800 / 300 |
| Power requirements | AC220V | AC220V | AC220V | AC220V | AC220V | AC220V | AC220V |
| Processing Performance | |||||||
| Drive method | Constant current drive | Constant current drive | Constant current drive | Constant current drive | Constant current drive | Constant current drive | Constant current drive |
| Frame frequency(Hz) | 50 & 60 | 50 & 60 | 50 & 60 | 50 & 60 | 50 & 60 | 50 & 60 | 50 & 60 |
| Refresh Rate (Hz) | ≥3840 / ≥7680 | ≥3840 / ≥7680 | ≥3840 / ≥7680 | ≥3840 / ≥7680 | ≥3840 / ≥7680 | ≥3840 / ≥7680 | ≥3840 / ≥7680 |
| Use Parameters | |||||||
| Life typical value(hrs) | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 | 100,000 |
| Work temperature(°C) | -20 to 55 | -20 to 55 | -20 to 55 | -20 to 55 | -20 to 55 | -20 to 55 | -20 to 55 |
| Storage temperature(°C) | -30 to 60 | -30 to 60 | -30 to 60 | -30 to 60 | -30 to 60 | -30 to 60 | -30 to 60 |
| Working humidity(RH) | 10-90% | 10-90% | 10-90% | 10-90% | 10-90% | 10-90% | 10-90% |
| Defective ratio | ≤4/100000 | ≤4/100000 | ≤4/100000 | ≤4/100000 | ≤4/100000 | ≤4/100000 | ≤4/100000 |
| Interaction | Interactive/Non-interactive | Interactive/Non-interactive | Interactive/Non-interactive | Interactive/Non-interactive | Interactive/Non-interactive | Interactive/Non-interactive | Interactive/Non-interactive |
